Solenoid Valve 108-070-0069

  • Variant: Width: 30 mm, Voltage: 24 V, Power: 6,8 W
  • Connection: CNOMO
More Information
System affiliationSystem 8
pneumatic operating mode3/2 NC
Overall Width30 mm
Electrical ConnectionDIN A
Orientation of the electr./pneum. InterfaceVariable
Manual OverrideWith Manual Override
Sheathing material solenoid coilDuroplast
1. Voltage (V)24 V
1. Kind of CurrentDC
1. Power [W]6,8 W
2. Power [VA]10,5 VA
Orifice Size Inlet1,7 mm
Orifice Size Exhaust1,7 mm
Min. Operating Pressure0,0 bar
Max. Operating Pressure10,0 bar
Permissible operating temperature min.-15 °C
Permissible operating temperature max.50 °C
nominal flow 1-284 l/min
nominal flow 2-394 l/min
Medium quality according to ISO standard3-3-3
leakage max. 4 ml/min
Drawing number1406 77 440/5195
