Solenoid Coil 108-030-0198 Ex

  • System 8
  • Width: 36 mm
  • Type of Approval: See product datasheet for approval details.
  • Primary Voltage: 220 V AC/50Hz
  • Power: 7,7 VA

For use in critical (potentially explosive) environments, nass magnet offers components of the System 8 and System 13 series. These are designed according to DIN EN 60079 and tested by the Physikalisch-Technische Bundesanstalt (PTB) according to the European Community Directive 2014/34/EU.

Explosion protection is ensured by using the components specified in the catalog and matched to each other. Furthermore, various country-specific approvals exist, such as the China Compulsory Certification (CCC), a certification system valid China.

More Information
System affiliationSystem 8
Power Level5
Type of protectionEx m
Overall Width36 mm
Electrical ConnectionStrand
Sheathing materialThermoplastic
1. Voltage (V)220 V
1. Kind of CurrentAC/50Hz
1. power [VA]7,7 VA
Voltage Tolerance [%]10 %
Voltage Tolerance min. [%]10 %
Drawing number0568 00.1-00/6731
Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account
datasheet for 108-030-0952; 108-030-0953; 108-030-0198; 108-030-0954; 108-030-0955; 108-030-0956; 108-030-0951
